TapNLink line

TapNLink Instant Wireless for Microcontrollers

TapNLink NFC, Bluetooth and Wi-Fi products for instant integration in microcontroller based systems.

All TapNLink modules benefit from our no-code / low-code IOT solution and support rapid integration in your electronic designs with:

  • Qualified wireless hardware and antennas
  • Rapid, secure implementation by configuration
  • Instant mobile UI apps with our no-code App Creator
  • Easy, rapid customization and cloud integration

The TapNLink line includes a range of wireless modules to meet diverse needs:

  • Near Field Communication (NFC)
  • Bluetooth Low Energy (BLE)
  • Wi-Fi





Try TapNLink and Our No-Code App Creator

Create user interfaces as iOS, Android or Web apps without writing a line of code. Our free App Creator is available to all users of TapNLink wireless modules. Just get a TapNLink PRIMER, then sign up here, and try it today!

Request Beta Test Access from contact@iotize.com












Where to Get Started Using My TapNLink

This page provides a starting point to access software downloads, technical documentation, videos and more.

If you have other questions, contact support@iotize.com !








TapNLink Modules & Key Features



  Wireless
Protocols
LPWAN
Protocols
Wire
Protocols
Modbus lwM2M JVM Power Consumtion
(Idle)
Typical Uses Availability
TnL-FIT213 NFC   S3P, SWD, UART 1 mA | -3 mA* (1 µA)
TnL-FIT203 NFC   S3P, SWD, UART 1 mA | -3 mA* (1 µA)
TnL-FIR203 NFC, BLE   S3P, SWD, UART 20 mA (80 µA)
TnL-FIR103 NFC, BLE   S3P, SWD, UART 20 mA (80 µA)
TnL-FIW103 NFC, BLE, Wi-Fi

S3P, SWD, UART

180 mA (80 µA)
TnL-FIL113 NFC, BLE LoRa S3P, SWD, UART 40 mA (0.4 µA)
TnL-FIL103 NFC LoRa S3P, SWD, UART 40 mA (0.4 µA)

   Yes         Preview         NFC 3-stroke configuration             Configuration          On-site monitoring       .  Remote Supervision

Note *: NFC modules can be configured to harvest energy from the mobile during use.






TapNLink

TapNLink BLE, NFC

TnL-FIR103-

TapNLink BLE, NFC (Type5) module for local connection of mobiles to microcontroller-based electronic systems.

Packing: Tray, 10 modules.
Android, iOS, Windows compatible.
CE, FCC, IC, ROHS, WEEE

Request a quote.

TapNLink BLE, NFC

TnL-FIR203

TapNLink BLE, NFC (Type5) module for local connection of mobiles to microcontroller-based electronic systems.

Packing: Tray, 10 modules.
Android, iOS, Windows compatible.
CE, FCC, IC, ROHS, WEEE

Request a quote.

TapNLink NFC

TnL-FIT203

TapNLink NFC (Type5) module for local connection of mobiles to microcontroller-based electronic systems.

Packing: Tray, 10 modules.
Android, iOS, Windows compatible.
CE, FCC, IC, ROHS, WEEE
Android, iOS, Windows compatible.
...

Request a quote.

TapNLink WiFi, BLE, NFC

TnL-FIW103

TapNLink module Wi-Fi, BLE, NFC (Type5) for local connection of microcontroller-based electronic systems to mobiles or to the Cloud

Packing: Tray, 10 modules.
Android, iOS, Windows compatible.
CE, FCC, IC, ROHS, WEEE

Request a quote.

Evaluation Kits

TapNLink Primer NFC-BLE-WiFi

IOTZ-TAPNLINK-PRIMER-NBW

TapNLink Primer evaluation kit for implementing TnL-FIW103 modules with Wi-Fi, BLE and NFC for interfaces connecting MCU-based electronic systems...

Android, iOS compatible. ArdTap library for Arduino integration.

59.00 €
